| ELECTRICAL DATE(STC) | |||||||
| Nominal Max. Power (Pmax) | 470w | 475w | 480w | 485w | 490w | 495w | 500w |
| Power Tolerance | 0~±3% | ||||||
| Opt. Operating Voltage (Vmp) | 35.69 | 35.88 | 36.06 | 36.25 | 36.43 | 36.62 | 36.79 |
| Opt. Operating Current (Imp) | 13.17 | 13.24 | 13.31 | 13.38 | 13.45 | 13.52 | 13.59 |
| Open Circuit Voltage (Voc) | 43.3 | 43.45 | 43.6 | 43.76 | 43.91 | 44.07 | 44.21 |
| Short Circuit Current (Isc) | 13.69 | 13.77 | 13.85 | 13.93 | 14.01 | 14.09 | 14.17 |
| Module Efficiency | 21.78% | 22.01% | 22.24% | 22.47% | 22.71% | 22.94% | 23.17% |
| 460 | 465 | 470 | 475 | 480 | 485 | |
|---|---|---|---|---|---|---|
| Maximum Power – Pmax [Wp] | 460 | 465 | 470 | 475 | 480 | 485 |
| Maximum Power Voltage – Vmp [V] | 30.57 | 30.74 | 30.93 | 31.11 | 31.30 | 31.48 |
| Maximum Power Current – Imp [A] | 15.05 | 15.13 | 15.20 | 15.27 | 15.34 | 15.41 |
| Open-circuit Voltage – Voc [V] | 35.67 | 35.92 | 36.17 | 36.42 | 36.67 | 36.92 |
| Short-circuit Current – Isc [A] | 15.72 | 15.77 | 15.82 | 15.86 | 15.90 | 15.95 |
| Module Efficiency STC [%] | 23.02 | 23.27 | 23.52 | 23.77 | 24.02 | 24.27 |
| Power Sorting | 0 ~ + 3 % | |||||
| Temperature Coefficient of Pmax | -0.26 %/°C | |||||
| Temperature Coefficient of Voc | -0.24 %/°C | |||||
| Temperature Coefficient of Isc | 0.046 %/°C | |||||
| STC: Irradiance 1000W/m², Cell Temperature 25°C, AM=1.5 | ||||||
